Round Flanged Connector
Round Flanged Connector
$0.00
Our highly skilled manufacturing team can create a connector for almost any need. We have plenty of different filter media dependant on your requirements.
Please refer to the chart below for the filter media available:
| Media Type | Description |
| Seeflex 040E | Seeflex 040E has no memory so will not fracture as a result of constant flexing. Temperature Range: -25-110°C Surge Temperature: 120°C Material Resistance: 1010 Ω Material: Clear ether based polyurethane. FDA Compliant: CFR 177.1680 & 177.2600 EU Approved: EC 1935/2004, 2023-2006, 2002/72, 10/2011 & USDA & 3A (20-). |
| Seeflex 020E | Seeflex 020E has no memory so will not fracture as a result of constant flexing. Temperature Range: -25-80°C Surge Temperature: 100°C Material Resistance: 1010 Ω Material: Clear ether based polyurethane. FDA Compliant: CFR 177.1680 & 177.2600 EU Approved: EC 1935/2004, 2023-2006, 2002/72/EC, 10/2011 & USDA & 3A (20-). |
| Seeflex 040AS | Seeflex 040AS is used in aplications with dust explosion hazardous areas. It has no memory so will not fracture as a result of constant flexing. Temperature Range: -25-95°C Material Resistance: 108 Ω Material: Clear ether based polyurethane with anti-static infusion. FDA Compliant: CFR 177.1680 & 177.2600 |
| LM4 | Perfect when some breathability is required to alleviate pressure. Used for higher temperature environments. Max. Operating Temperature: 130°C continuous Surge Temperature: 120°C Air Permeability: 0.25-0.5 (cm3/cm2/sec@125pa) FDA Compliant: CFR 177.1680 & 177.2600 |
| Kevlar | Kevlar is suitable for over pressure and potentially explosive applications, as well as food processing. FDA Compliant: CFR 21 177.1632 |
| Teflex | Suitable for extreme temperatures and highly resistant against alkalis/acidic/caustic products. Can be used on products across the full PH scale (either caustic or acid) Continuous Service Temperature: 260°C Short Term Surges Temperature: 280°C Air Permeability: 0.6 (cm3/cm2/sec@125pa) FDA Compliant: CFR 21 177.1150 |
Don't hesitate to Contact Us with your enquiry.
